Zoom MS-70CDR+
- 140+ guitar and bass effects, including modulation, chorus, delay, and reverb
- Use up to 6 effects at the same time
- 100 Patch slots with 80 presets
- Analog circuit with minimal sound deterioration
- Single stompbox design
- Stereo input and output supports effects like stereo chorus and delays
- 4x Cross Key switches (MEMORY / SCROLL) for easy operation by foot
- Improved UI for easier navigation and control
- Color coded LCD backlight for selected effect category
- Runs on 2 AA batteries or AC Adapter
Specs
| MAXIMUM NUMBER OF SIMULTANEOUS EFFECTS | 6 effects | |
| USER PATCH MEMORIES | 100 | |
| SAMPLING FREQUENCY | 44.1 kHz | |
| A/D CONVERSION | 24-bit 128× oversampling | |
| D/A CONVERSION | 24-bit 128× oversampling | |
| SIGNAL PROCESSING | 32-bit | |
| FREQUENCY RESPONSE | 20 Hz - 20 kHz (+0.5 dB/-0.5 dB) (when 10kΩ load) | |
| DISPLAY | 160×128 dot-matrix LCD | |
| INPUTS | L/R | Standard mono phone jacks Rated input level: −20 dBu Input impedance (line): 470 kΩ |
| OUTPUTS | L/R | Standard mono phone jacks Maximum output level: +7.2 dBu (when output impedance 10 kΩ or higher) |
| INPUT S/N | 122 dB | |
| NOISE FLOOR (RESIDUAL NOISE) | L/R | –100 dBu |
| POWER | AC adapter: 9V DC 500mA center negative (ZOOM AD-16) 2 AA batteries (alkaline, lithium or rechargeable NiMH batteries) | |
| ESTIMATED OPERATION TIMES | • These values are "approximate. • Battery operation times were determined using in-house testing methods. They will vary greatly according to use conditions." | Alkaline batteries: about 7 hours (about 5 hours using using batteries) NiMH batteries (1900 mAh): about 6.5 hours (about 5 hours using stereo input) Lithium batteries: about 14 hours (about 10 hours using stereo input) |
| USB | Port: USB 2.0 Type-C / Supported cable type: Type-C Handy Guitar Lab: USB 1.1 Full Speed • Use a USB cable that supports data transfer. USB bus power is supported. | |
| DIMENSIONS | 133 mm (D) × 79 mm (W) × 61 mm (H) | |
| WEIGHT | 368 g (excluding batteries) 415 g (including batteries) | |
| NOTE: 0 DBU = 0.775 V |
$51.00
Original: $169.99
-70%Zoom MS-70CDR+—
$169.99
$51.00Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
- 140+ guitar and bass effects, including modulation, chorus, delay, and reverb
- Use up to 6 effects at the same time
- 100 Patch slots with 80 presets
- Analog circuit with minimal sound deterioration
- Single stompbox design
- Stereo input and output supports effects like stereo chorus and delays
- 4x Cross Key switches (MEMORY / SCROLL) for easy operation by foot
- Improved UI for easier navigation and control
- Color coded LCD backlight for selected effect category
- Runs on 2 AA batteries or AC Adapter
Specs
| MAXIMUM NUMBER OF SIMULTANEOUS EFFECTS | 6 effects | |
| USER PATCH MEMORIES | 100 | |
| SAMPLING FREQUENCY | 44.1 kHz | |
| A/D CONVERSION | 24-bit 128× oversampling | |
| D/A CONVERSION | 24-bit 128× oversampling | |
| SIGNAL PROCESSING | 32-bit | |
| FREQUENCY RESPONSE | 20 Hz - 20 kHz (+0.5 dB/-0.5 dB) (when 10kΩ load) | |
| DISPLAY | 160×128 dot-matrix LCD | |
| INPUTS | L/R | Standard mono phone jacks Rated input level: −20 dBu Input impedance (line): 470 kΩ |
| OUTPUTS | L/R | Standard mono phone jacks Maximum output level: +7.2 dBu (when output impedance 10 kΩ or higher) |
| INPUT S/N | 122 dB | |
| NOISE FLOOR (RESIDUAL NOISE) | L/R | –100 dBu |
| POWER | AC adapter: 9V DC 500mA center negative (ZOOM AD-16) 2 AA batteries (alkaline, lithium or rechargeable NiMH batteries) | |
| ESTIMATED OPERATION TIMES | • These values are "approximate. • Battery operation times were determined using in-house testing methods. They will vary greatly according to use conditions." | Alkaline batteries: about 7 hours (about 5 hours using using batteries) NiMH batteries (1900 mAh): about 6.5 hours (about 5 hours using stereo input) Lithium batteries: about 14 hours (about 10 hours using stereo input) |
| USB | Port: USB 2.0 Type-C / Supported cable type: Type-C Handy Guitar Lab: USB 1.1 Full Speed • Use a USB cable that supports data transfer. USB bus power is supported. | |
| DIMENSIONS | 133 mm (D) × 79 mm (W) × 61 mm (H) | |
| WEIGHT | 368 g (excluding batteries) 415 g (including batteries) | |
| NOTE: 0 DBU = 0.775 V |
